Author Topic: Just another mid 90's Toyota Tercel  (Read 7791 times)

AstroVannin

  • Sr. Member
  • ****
  • Offline Offline
  • Posts: 625
Just another mid 90's Toyota Tercel
« on: October 06, 2010, 07:00:19 AM »

I FINALLY got off my ass and decided to build a replacment for my old shitty Turbo Tercel.

Car is a 1994 Toyota Tercel DX, 3E-E, 5 speed

* 3E-E 12v sohc
* Volvo T3
* WEIR Log mani
* WEIR 2.5 downpipe
* WEIR 2.5 chargepipes
* DSM intercooler
* Piersburg adjustable BOV
* aluminim dual core civic rad
* slim fan
* Supra 315cc injectors
* AEM F/IC
* AEM wideband
* Crane Cams ignition box with 2step

OTHER JUNK

* 1994 Paseo interior
* OEM Tach cluster
* VDO Gauges
* JY Alpine CD player
* OEM Tercel carpet floor mats
* MOMO steering wheel
* Celica GT-S dual bend shifter
* gc springs (250fr /300rr)
* 19mm Paseo front sway bar
* 25mm Ranger rear bar
* 195/60R14 BFG's on Enkei Daiseys
* 185/60R13 Yok A032R's on Speedlines
* 195/50R15 Nexens on "mystery 15" 5 spokes"
* 205/50R13 Hoosier Auto X slicks (trashed) on 13" CSA's













and some pics on the old suspention ... Too soft TEIN springs and no sway bars.





glustic

  • Certified OG
  • *****
  • Offline Offline
  • Posts: 2502
  • Jay is a fucking homo
Re: Just another mid 90's Toyota Tercel
« Reply #1 on: October 06, 2010, 10:13:32 AM »

Very nice sir. Looks like there is plenty room on space in the bay. Must be a pain in the ass to change the oil however.
Logged
fucking box started smoking and i saw a flame start up so i grabbed a bucket of water and splashed it on the breaker box.. nbspnbsp BIG FUCKING MISTAKE

-BUK

ApexSilver06MR

  • RealHomeMadeTurbo's "pee wee"
  • Global Moderator
  • Certified OG
  • *****
  • Offline Offline
  • Posts: 9872
  • RealHomeMadeTurbo Resident Cocksmith!
Re: Just another mid 90's Toyota Tercel
« Reply #2 on: October 06, 2010, 11:40:19 AM »

drop a 4e and be done and tock the top mount.


dont get me started with tercels and paseos.

i kinda miss those forums.  the one on network54 and TO
Logged
pee wee for the size of my p..........

Nor*Cal Spoolin'#039#039 Nig Nog

Lowerit

  • Certified OG
  • *****
  • Offline Offline
  • Posts: 101185
Re: Just another mid 90's Toyota Tercel
« Reply #3 on: October 06, 2010, 04:54:19 PM »

what a dirty pos...

the intercooler and turbo placement are badass thou.   O0

How much you have in it now dustin? $500?

Logged
fuck you

shadow

  • Certified OG
  • *****
  • Offline Offline
  • Posts: 2160
  • out either bangin gears or your mom
Re: Just another mid 90's Toyota Tercel
« Reply #4 on: October 06, 2010, 05:22:58 PM »

drop a 4e and be done and tock the top mount.


dont get me started with tercels and paseos.

i kinda miss those forums.  the one on network54 and TO

paseopimp? lol
Logged
'Get the fucking handout and give it to me. I'll put a "Sponsored by Darkelvis Racing" banner on my drag car, and spend the money on crack and hookers.'

crxvtec91

  • Administrator
  • Certified OG
  • *****
  • Offline Offline
  • Posts: 8343
  • RIP old hmt. SloS13 for King!!!
Re: Just another mid 90's Toyota Tercel
« Reply #5 on: October 06, 2010, 05:23:13 PM »

Looks sweet, what are you using to tune it?
Logged
My build thread; http://www.realhomemadeturbo.com/forum/index.php?topic=2444.0


I like my girls like I like my cars, rich and retarded.

AstroVannin

  • Sr. Member
  • ****
  • Offline Offline
  • Posts: 625
Re: Just another mid 90's Toyota Tercel
« Reply #6 on: October 06, 2010, 05:35:44 PM »

Its looks like theres less clearance then there really is for the oil filter.... its not bad at all.

4EFTE ? Nah.

As far as how much Im into it for ..... probably a little more then $500, but less then $1000 for sure.

For tuning, Ive got an AEM F/IC .... I traded a set of ROnals I had on my Accord for it (F/IC was new in the box) I think it should work pretty well.

SloS13

  • RHMT Ex-President
  • Administrator
  • Certified OG
  • *****
  • Offline Offline
  • Posts: I am a geek!!
  • My avatar is broken
Re: Just another mid 90's Toyota Tercel
« Reply #7 on: October 06, 2010, 05:47:36 PM »

F/IC FTW

Rippers STAT
Logged

92CXyD

  • Twincharged Smeghead
  • Global Moderator
  • Certified OG
  • *****
  • Online Online
  • Posts: 6790
  • I look around and all I see is Smegheads
Re: Just another mid 90's Toyota Tercel
« Reply #8 on: October 06, 2010, 06:07:25 PM »

This is peeking my interest.  ;D

Vid and more comprehensive build thread would be great. ;D

I'm thinking of doing a Toyota build in the future and I'm thinking a 'rolla.  :yes: ;D

AstroVannin

  • Sr. Member
  • ****
  • Offline Offline
  • Posts: 625
Re: Just another mid 90's Toyota Tercel
« Reply #9 on: October 06, 2010, 07:36:24 PM »

Yeah, Ive gotta go out and get some tuning done.... vids will follow.

When it come apart in the winter Il make a better build thread per say.

My goal for this year is to get it all together and have it running before I park it for the winter. Over the winter I want to take it all back apart, rebuild the engine and send the turbo to Blaast ... as well as tidy up the engine bay.
« Last Edit: October 06, 2010, 07:45:14 PM by AstroVannin »
Logged

Joseph Davis

  • Verbal Assault Technician
  • RHMT Moderator
  • Certified OG
  • *****
  • Offline Offline
  • Posts: 34733
  • Eugenics prevents retards like widebody93
    • TURBO THIS
Re: Just another mid 90's Toyota Tercel
« Reply #10 on: October 07, 2010, 08:17:14 PM »

Between the CB7 and offbeat Toyota fetishes... we need to drink, sir.

AstroVannin

  • Sr. Member
  • ****
  • Offline Offline
  • Posts: 625
Re: Just another mid 90's Toyota Tercel
« Reply #11 on: October 08, 2010, 12:15:11 AM »

Ah ha ha ha...

Il take that as a compliment.

also .... ygpm

AstroVannin

  • Sr. Member
  • ****
  • Offline Offline
  • Posts: 625
Re: Just another mid 90's Toyota Tercel
« Reply #12 on: October 09, 2010, 08:12:39 AM »

Ive been hanging onto this 3" crush bent system from my old car for a few years.... finally paid off.

The muffler is from a Magnaflow that has been sitting around in the garage for a bit now too.

Im planning to have the DP go straight into a 2.5" cherry bomb, then the 3" system, with the magnaflow at the back. Should be nice and quiet most of the time and still flow good.



t_cel_t

  • Certified OG
  • *****
  • Offline Offline
  • Posts: 3147
Re: Just another mid 90's Toyota Tercel
« Reply #13 on: October 09, 2010, 08:17:18 AM »

bitchin man, hope to have my 91 terc going soon. megasquirt and e85 is done, just need to tap the pan, make charge pipe, and down pipe.
Logged
malone labe

I think all cop cars need to have turbo. nbspnbsp Then they would understand the necessity of putting your foot down and how uncontrollable the urge is to fucking rail on that shit.

Teg2boo

  • Certified OG
  • *****
  • Offline Offline
  • Posts: 4261
Re: Just another mid 90's Toyota Tercel
« Reply #14 on: October 09, 2010, 10:22:19 AM »

How much HP/torque can you expect with a Tercel build?

I have the exact same Motomaster battery, but mine leak acid everywhere....
Logged


damn you guys too? its a fucking forum not a court room!
 Its not a forum its a gang.

AstroVannin

  • Sr. Member
  • ****
  • Offline Offline
  • Posts: 625
Re: Just another mid 90's Toyota Tercel
« Reply #15 on: October 09, 2010, 05:27:52 PM »

Ideally I would like to have 200/225whp ... but we will see how it goes.

plymouth

  • Jr. Member
  • **
  • Offline Offline
  • Posts: 47
  • fuck you
Re: Just another mid 90's Toyota Tercel
« Reply #16 on: October 10, 2010, 02:43:07 AM »

200 in that car has got to be funny.
